Description
Stainless steel sensors are recommended when the greatest accuracy is required, for example to measure manifold air pressure. AEM’s sensor kits contain everything you need to mount a sensor, including connector, pins and 1/8 NPT fitting.
Specifications:
- Accuracy: +/- 1% Full Scale over -40C to 105C includes Repeatability, Hysteresis and Linearity
- Operating Temp: -40C to 105C / -40F to 221F
- Burst Pressure: 10,000PSI
- Response Time: < 1ms
- Vibration:100 to 2000Hz, 20g Sinusoidal, 3 Axes
- Sensor Body: Stainless Steel
- Wetted Materials: 304L & 316L Stainless Steel
- Thread: 1/8″ NPT Male Thread
- Weight: < 85 Grams
- Supply Current:
- Output: .5 to 4.5Vdc Linear
- Elec. Termination: Integral weatherproof connector, includes mating connector, pins & pin lock
- Includes: 1000 PSIg Stainless Sensor, Connector, Pins, Pin Lock, 1/8″ NPT to -4 Adapter
